GEC Semiconductors: Vintage Transistors / Diodes Collection
This site contains my collection of vintage transistors and diodes, most of them included with their original package or sleeves. The devices are produced in the late fifties and early sixties except the MOSFET's from Sony they where made in 1975. Enjoy the collectables and click on the picture links for more details. Suggestions regarding these transistors are welcome. I'm always looking for new semiconductor items to complete my collection, so if you would like to sell or exchange something, please contact me, jan@transparentsound.com.
| EW80 GEC | Type | : | EW80, PNP Germanium Transistor Low Power |
|
|
Manufacturer | : | GEC |
| Year | : | End Fifties | |
| Package, Case style | : | Carton box, Black Metal Can | |
| Spec's | : |
Vceo(max)=- ?V, Vcbo(max)=- ?V, Hfe= ?, Ic=- ?mA, Icbo=5uA, P= ?mW, ft= ?kHz, Cobo= ?pF |
|
| : | Picture1, Picture2, Picture3 |
| GET67 GEC | Type | : | GET67, PNP Diffused Germanium Transistor |
|
|
Manufacturer | : | GEC Semiconductors |
| Year | : | Perhaps mid fifties | |
| Package, Case style | : | None, TO-8var | |
| Spec's | : | Vceo=-?V, Vcbo=-?V, Hfe=?, Ic=-?mA, P=?mW | |
| Photo's | : | Picture1, Picture1, |
| GET101 GEC | Type | : | GET101, PNP Germanium Alloy Transistor |
|
|
Manufacturer | : | GEC Semiconductors also produced by Mullard Ltd. |
| Year | : | Early Sixties | |
| Package, Case style | : | None, GEC & Mullard: Red plastic over metal tube | |
| Spec's | : | Vceo(max)=- ?V, Vcbo(max)=- ?V, Hfe= ?, Ic=- ?mA, Icbo=?uA, P= ?mW, ft= ?MHz, Cobo= ?pF | |
| Photo's | : | Picture1 |
| GET102 GEC | Type | : | GET102, PNP Germanium Alloy Transistor |
|
|
Manufacturer | : | GEC Semiconductors also produced by Mullard Ltd. |
| Year | : | Early Sixties | |
| Package, Case style | : | None, GEC & Mullard: Red plastic over metal tube | |
| Spec's | : | Vceo(max)=- ?V, Vcbo(max)=- 30V, Hfe= 100, Ic=- 1000mA, Icbo=?uA, P= 200mW, ft= 1.5MHz, Cobo= 90pF | |
| Photo's | : | Picture1, Picture2 |
| GET103/CV7074 GEC | Type | : | GET103, PNP Germanium Alloy Transistor |
|
|
Manufacturer | : | GEC Semiconductors also produced by Mullard Ltd. |
| Year | : | Early Sixties | |
| Package, Case style | : | None, GEC & Mullard: Red plastic over metal tube, R11, CV-series: Grey plastic over metal tube | |
| Spec's | : | Vceo(max)=- ?V, Vcbo(max)=- 30V, Hfe= 55, Ic=- 1000mA, Icbo=?uA, P= 200mW, ft= 1MHz, Cobo= 2pF | |
| Photo's | : | Picture1, Picture2 |
| GET104 GEC | Type | : | GET104, PNP Germanium Alloy Transistor |
|
|
Manufacturer | : | GEC Semiconductors also produced by Mullard Ltd. |
| Year | : | Early Sixties | |
| Package, Case style | : | None, GEC & Mullard: Red plastic over metal tube, R11 | |
| Spec's | : | Vceo(max)=- ?V, Vcbo(max)=- 30V, Hfe= 55, Ic=- 1000mA, Icbo=?uA, P= 200mW, ft= 1MHz, Cobo= ?pF | |
| Photo's | : | Picture1 |
| GET115 GEC | Type | : | GET115, PNP Power Germanium Alloy Transistor |
|
|
Manufacturer | : | GEC Semiconductors also produced by Mullard Ltd. |
| Year | : | Early Sixties | |
| Package, Case style | : | None, GEC: TMM6 Black Metal | |
| Spec's | : | Vceo(max)=- ?V, Vcbo(max)=- 15V, Hfe=30, Ic=- 1000mA, Icbo=?uA, P= 800mW, ft= 1MHz, Cobo= ?pF | |
| Photo's | : | Picture1, Picture1, |
| GET120 GEC | Type | : | GET120, PNP Power Germanium Alloy Transistor |
|
|
Manufacturer | : | GEC Semiconductors also produced by Mullard Ltd. |
| Year | : | Early Sixties | |
| Package, Case style | : | None, GEC: TMM6 Black Metal | |
| Spec's | : | Vceo(max)=- ?V, Vcbo(max)=- 30V, Hfe=20, Ic=- 1000mA, Icbo=?uA, P= 800mW, ft= 1,4MHz, Cobo= ?pF | |
| Photo's | : | Picture1, Picture1 |
| GET571 GEC | Type | : | GET571, PNP High Power Germanium Alloy Transistor |
|
|
Manufacturer | : | GEC Semiconductors |
| Year | : | Early Sixties | |
| Package, Case style | : | None, Metal case MD2 | |
| Spec's | : | Vceo(max)=- ?V, Vcbo(max)=- 16V, Hfe= 30, Ic=- 12A, Icbo=?uA, P= 18W, ft= ?MHz, Cobo= ?pF | |
| Photo's | : | Picture1, Picture1 |
| GET691 GEC | Type | : | GET691, PNP Germanium Transistor (New) |
|
|
Manufacturer | : | GEC Semiconductors |
| Year | : | Early Sixties | |
| Package, Case style | : | None, Green plastic over metal tube, R11 | |
| Spec's | : | Vceo(max)=- ?V, Vcbo(max)=- 20V, Hfe= 60, Ic=- 10mA, Icbo=?uA, P= 45mW, ft= 30MHz, Cobo= ?pF | |
| Photo's | : | Picture1, Picture1 |
| GET692 GEC | Type | : | GET692, PNP Germanium Transistor (New) |
|
|
Manufacturer | : | GEC Semiconductors |
| Year | : | Early Sixties | |
| Package, Case style | : | None, Green plastic over metal tube, R11 | |
| Spec's | : | Vceo(max)=- ?V, Vcbo(max)=- 20V, Hfe= 60, Ic=- 10mA, Icbo=?uA, P= 45mW, ft= 40MHz, Cobo= ?pF | |
| Photo's | : | Picture1, Picture1 |
| GET873 GEC | Type | : | GET873, PNP Germanium Alloy Transistor |
|
|
Manufacturer | : | GEC Semiconductors also produced by Mullard Ltd. |
| Year | : | Early Sixties | |
| Package, Case style | : | None, GEC: Blue plastic over metal tube | |
| Spec's | : | Vceo(max)=- ?V, Vcbo(max)=- 15V, Hfe= 50, Ic=- 10mA, Icbo=?uA, P= 75mW, ft= 6MHz, Cobo= ?pF | |
| Photo's | : | Picture1, Picture1 |
| GET875/CV7087 GEC | Type | : | GET873, PNP Germanium Alloy Transistor |
|
|
Manufacturer | : | GEC Semiconductors also produced by Mullard Ltd. |
| Year | : | Early Sixties | |
| Package, Case style | : | None, GEC: Blue plastic over metal tube | |
| Spec's | : | Vceo(max)=- ?V, Vcbo(max)=- 15V, Hfe= 90, Ic=- 150mA, Icbo=?uA, P= 75mW, ft= 20MHz, Cobo= ?pF | |
| Photo's | : | Picture1, Picture1 |
| GET882 GEC | Type | : | GET882, PNP Germanium Alloy Transistor |
|
|
Manufacturer | : | GEC Semiconductors also produced by Mullard Ltd. |
| Year | : | Early Sixties | |
| Package, Case style | : | None, GEC: TO-5 Metal | |
| Spec's | : | Vceo(max)=- ?V, Vcbo(max)=- 20V, Hfe=150, Ic=- 500mA, Icbo=5uA, P= 120mW, ft= 12MHz, Cobo= ?pF | |
| Photo's | : | Picture1, Picture2 |
| SX51SC GEC | Type | : | SX651AC, Silicon Diode |
|
|
Manufacturer | : | GEC Semiconductors |
| Year | : | Perhaps mid fifties | |
| Package, Case style | : | Carton box, TO-8var | |
| Spec's | : | Reverse Voltage=-?V(max), Forward Current=?mA, Peak Forward Current=?mA | |
| Photo's | : | Picture1, Picture2 |
| SX633R GEC | Type | : | SX633R, Silicon Diode |
|
|
Manufacturer | : | GEC Semiconductors |
| Year | : | Perhaps mid fifties | |
| Package, Case style | : | Carton box, TO-8var | |
| Spec's | : | Reverse Voltage=-?V(max), Forward Current=?mA, Peak Forward Current=?mA | |
| Photo's | : | Picture1, Picture2 |
| SX634 GEC | Type | : | SX634, Silicon Diode |
|
|
Manufacturer | : | GEC Semiconductors |
| Year | : | Perhaps mid fifties | |
| Package, Case style | : | Carton box, TO-8var | |
| Spec's | : | Reverse Voltage=-?V(max), Forward Current=?mA, Peak Forward Current=?mA | |
| Photo's | : | Picture1, Picture2 |
| SX640 GEC | Type | : | SX640, Silicon Diode |
|
|
Manufacturer | : | GEC Semiconductors |
| Year | : | Perhaps mid fifties | |
| Package, Case style | : | Carton box, TO-8var | |
| Spec's | : | Reverse Voltage=-?V(max), Forward Current=?mA, Peak Forward Current=?mA | |
| Photo's | : | Picture1, Picture2 |
| SX643 GEC | Type | : | SX643, Silicon Diode |
|
|
Manufacturer | : | GEC Semiconductors |
| Year | : | Perhaps mid fifties | |
| Package, Case style | : | Carton box, TO-8var | |
| Spec's | : | Reverse Voltage=-?V(max), Forward Current=?mA, Peak Forward Current=?mA | |
| Photo's | : | Picture1, Picture2, |
| SX645 GEC | Type | : | SX645, Silicon Diode |
|
|
Manufacturer | : | GEC Semiconductors |
| Year | : | Perhaps mid fifties | |
| Package, Case style | : | Carton box, TO-8var | |
| Spec's | : | Reverse Voltage=-?V(max), Forward Current=?mA, Peak Forward Current=?mA | |
| Photo's | : | Picture1, Picture2, |
| SX782 GEC | Type | : | SX782, Silicon Diode |
|
|
Manufacturer | : | GEC Semiconductors |
| Year | : | Perhaps mid fifties | |
| Package, Case style | : | Carton box, TO-8var | |
| Spec's | : | Reverse Voltage=-?V(max), Forward Current=?mA, Peak Forward Current=?mA | |
| Photo's | : | Picture1, Picture2, |
| SX781 GEC | Type | : | SX781, Silicon Diode |
|
|
Manufacturer | : | GEC Semiconductors |
| Year | : | Perhaps mid fifties | |
| Package, Case style | : | Carton box, TO-8var | |
| Spec's | : | Reverse Voltage=-?V(max), Forward Current=?mA, Peak Forward Current=?mA | |
| Photo's | : | Picture1, Picture2, |
| S1 GEC | Type | : | S1, PNP Germanium Transistor |
|
|
Manufacturer | : | GEC Semiconductors |
| Year | : | Perhaps mid fifties | |
| Package, Case style | : | Carton box, TO-8var | |
| Spec's | : | Vceo=-?V, Vcbo=-?V, Hfe=?, Ic=-?mA, P=?mW | |
| Photo's | : | Picture1, Picture2 |
