This site contains my collection of vintage transistors and diodes, most of them included with their original package or sleeves. The devices are produced in the late fifties and early sixties except the MOSFET's from Sony they where made in 1975. Enjoy the collectables and click on the picture links for more details. Suggestions regarding these transistors are welcome. I'm always looking for new semiconductor items to complete my collection, so if you would like to sell or exchange something, please contact me, jan@transparentsound.com.
| S35 BCC | Type | : | S35, Silicon Junction Diode |
|
|
Manufacturer | : | Brush Crystal Company |
| Year | : | Perhaps mid fifties | |
| Package, Case style | : | Carton box, TO-8var | |
| Spec's | : | Reverse Voltage=-160V(max), Forward Current=30mA, Peak Forward Current=100mA. Max. Power Dissipation 250mW, Cf=10pF | |
| Photo's | : | Picture1, Picture2 Many thanks to Andrew Wylie from England for the exact information regarding this diode: Information about them is hard to find, but they used the same packaging as Intermetall in Germany. Both used a logo of a small hexagon with a letter in it - B for Brush, I for Intermetall |
UK-Military CV-series; Crystal Valve or Common Valve:
| CV425 | Type | : | CV425, Germanium Diode, see also CG1C, GEX44, GEX45/1 and the OA74 |
|
|
Manufacturer | : | UK-Military CV-series, see Brand history on this website |
| Year | : | Early sixties | |
| Package, Case style | : | Sealed plastic bag, DO-14 | |
| Spec's | : | Forward Current(at1V)= 5mA, Reverse Voltage=65V(max), Peak Forward Current=30mA, Max Reverse Current=1mA | |
| Photo's | : | Picture1 |
| CV4073 | Type | : | CV4073, Germanium Diode |
|
|
Manufacturer | : | UK-Military CV-series, see Brand history on this website |
| Year | : | Early sixties | |
| Package, Case style | : | Sealed plastic bag, TO-8var | |
| Spec's | : | Forward Current(at1V)= ?mA, Reverse Voltage=?V(max), Peak Forward Current=?mA, Max Reverse Current=?mA | |
| Photo's | : | Picture1 |
| CV7008 | Type | : | CV7008, Germanium Transistor |
|
|
Manufacturer | : | UK-Military CV-series, see Brand history on this website |
| Year | : | Early sixties | |
| Package, Case style | : | Sealed plastic bag, TO-8var | |
| Spec's | : | Vceo=-?V, Vcbo=-?V, Hfe=?, Ic=-?mA, Icbo=-?uA, P=?mW, ft=?MHz(max), Cobo=?pF | |
| Photo's | : | Picture1, Picture2 |
| SA495 | Type | : | SA495, PNP Silicon Transistor |
|
|
Manufacturer | : | GEC Plessey Semiconductors "Semics" |
| Year | : | Early sixties | |
| Package, Case style | : |
TO-1, The SA495 is a PNP Surface Alloy Silicon Transistor produced in 1961 by GEC Plessey Semiconductors. I didn’t discover the difference between the SA495 and SA495A. This type has a full gold plated encapsulation, other devices could be different like metal colour or a combination of these two colours. |
|
| Spec's | : | Vceo=-25V, Vcbo=-25V, Hfe=?, Ic=-50mA, Icbo=-1uA, P=150mW, ft=?MHz(max), Cobo=12pF | |
| Photo's | : | Picture1, Picture2, Picture3 |
| ST140 | Type | : | ST140, NPN Silicon Epitaxial Planar Transistor |
|
|
Manufacturer | : | Sinclair, brand labeled from Philco |
| Year | : | Early sixties | |
| Package, Case style | : |
?, In 1958 Fairchild marketed their first silicon diffusion mesa transistors to RCA, and then planar transistor in 1959. In early 1960s the epitaxial growth technology is invented and adopted by many other semiconductor manufactures. The ST140 is a NPN Silicon Epitaxial Planar Transistor from Sinclair, although this company didn’t produce transistors but applied them in their own products. I think they brand labelled these devices from Motorola identical Van der Heem from Holland did with their semiconductors |
|
| Spec's | : | Vceo=-25V, Vcbo=-25V, Hfe=15-40, Ic=-50mA, Icbo=-1uA, P=680mW, ft=700MHz(max), Cobo=2.2pF | |
| Photo's | : | Picture1, Picture2, Picture3 |
| ST141 | Type | : | ST141, NPN Silicon Epitaxial Planar Transistor |
|
|
Manufacturer | : | Sinclair, brand labeled from Philco |
| Year | : | Early sixties | |
| Package, Case style | : |
?, In 1958 Fairchild marketed their first silicon diffusion mesa transistors to RCA, and then planar transistor in 1959. In early 1960s the epitaxial growth technology is invented and adopted by many other semiconductor manufactures. The ST140 is a NPN Silicon Epitaxial Planar Transistor from Sinclair, although this company didn’t produce transistors but applied them in their own products. I think they brand labelled these devices from Motorola identical Van der Heem from Holland did with their semiconductors |
|
| Spec's | : | Vceo=-25V, Vcbo=-25V, Hfe=30-150, Ic=-50mA, Icbo=-1uA, P=680mW, ft=700MHz(max), Cobo=2.5pF | |
| Photo's | : | Picture1, Picture2, Picture3 |
| MAS21 | Type | : | MAS21, Germanium Transistor |
|
|
Manufacturer | : | ? |
| Year | : | 19?? | |
| Package, Case style | : | ? | |
| Spec's | : | ?, (I'm looking for technical data) | |
| Photo's | : | Picture1, Picture2, Picture3 |
| AD149 | Type | : | AD149, PNP Power Germanium Transistor |
|
|
Manufacturer | : | Tungsram |
| Year | : | Sixties | |
| Package, Case style | : | Carton box, TO-3 | |
| Spec's | : | Vceo=-30V, Vcbo=-50V, Hfe=30, Ic=-3.5A, P=22W | |
| : | Picture1, Picture2, Picture3 |
| EFT125 | Type | : | EFT125, PNP Germanium Low Power Transistor |
|
|
Manufacturer | : | Thomson |
| Year | : | ? | |
| Package, Case style | : | none, Can | |
| Spec's | : | Vcbo=-?V, Hfe=?, Ic=-?mA, Icbo=?uA, P=?mW | |
| Photo's | : | Picture1, Picture2 |
| BFY50 | Type | : | BFY50, NPN General Purpose Medium Silicon Transistor |
|
|
Manufacturer | : | Valvo |
| Year | : | Week 41, 1969 | |
| Package, Case style | : | Carton box, TO-39 | |
| Spec's | : | Vceo=35V, Vcbo=-/V, Hfe=30-112, Ic=1000mA, Icbo=?uA, P=800mW, f(T)=60MHz | |
| : | Picture1, Picture2, Picture3 |
| VT200 | Type | : | VT200, Silicon Avalanche, Integrated Bridge Rectifier |
|
|
Manufacturer | : | Varo Semiconductor Inc. |
| Year | : | 7615, Week 15, 1976 | |
| Package, Case style | : | None, TO-3 outline | |
| Spec's | : | Reverse Voltage=200V(max), Reverse Voltage=140V(continous), Forward Current=1500A (Peak), DC Forward Current=25A | |
| : | Picture1, Picture2, Picture3, (Donated by Robert Ettema from the Netherlands) |
| 1N4436FT | Type | : | 1N4436FT, Silicon Avalanche, Integrated Bridge Rectifier |
|
|
Manufacturer | : | Varo Semiconductor Inc. |
| Year | : | 7350, Week 50, 1973 | |
| Package, Case style | : | None, TO-3 outline | |
| Spec's | : | Reverse Voltage=200V(max), Reverse Voltage=140V(continous), Forward Current=600A (Peak), DC Forward Current=10A | |
| : | Picture1, Picture2, Picture3, (Donated by Robert Ettema from the Netherlands) |
| Unknown Device | Type | : | Unknown device |
|
|
Manufacturer | : | Unknown |
| Year | : | Mid sixties | |
| Package, Case style | : | None, TO-24 | |
| Spec's | : | Vcbo=-?V, Vceo=-?V, Hfe=?, Ic=-?mA, Icbo=?uA, P=?mW, ft=?MHz, Cobo=?pF | |
| : | Picture1, Picture2 |
