AEI/BTH & Hivac Semiconductors Transistors / Diodes Collection
This site contains my collection of vintage transistors and diodes, most of them included with their original package or sleeves. The devices are produced in the late fifties and early sixties except the MOSFET's from Sony they where made in 1975. Enjoy the collectables and click on the picture links for more details. Suggestions regarding these transistors are welcome. I'm always looking for new semiconductor items to complete my collection, so if you would like to sell or exchange something, please contact me, jan@transparentsound.com.
| XFT2 (Hivac) | Type | : | XFT2, Germanium PNP transistor Low Power |
|
|
Manufacturer | : | Hivac |
| Year | : | End Fifties | |
| Package, Case style | : | None, Blue/Green with several colored dots on the case of the transistor and letter "H" on it from Hivac. | |
| Spec's | : |
Vceo(max)=-?V, Vcbo(max)=-?V, Hfe=?, Ic=-?mA, Icbo=?uA, P=?mW, ft=?kHz, Cobo=?pF |
|
| Photo's | : | Picture1, Picture2, Picture3, Picture4 |
| GT11 (BTH) | Type | : | GT11, Intermediate and High Speed Switching Germanium PNP transistor Low Power |
|
|
Manufacturer | : | British Thomson Houston |
| Year | : | End Fifties | |
| Package, Case style | : | None, Blue/Green with yellow top and letter "V" on it and white spot at the side of the transistor | |
| Spec's | : |
Vceo(max)=-?V, Vcbo(max)=-9V, Hfe=30, Ic=-10mA, Icbo=5uA, P=100mW, ft=420kHz, Cobo=?pF |
|
| Photo's | : | Picture1, Picture2 |
| GT12 (BTH) | Type | : | GT12, Intermediate and High Speed Switching Germanium PNP transistor Low Power |
|
|
Manufacturer | : | British Thomson Houston |
| Year | : | End Fifties | |
| Package, Case style | : | None, Grey/Soft blue color with white top and letter "A" on it and white spot at the side of the transistor | |
| Spec's | : |
Vceo(max)=-?V, Vcbo(max)=-9V, Hfe=60, Ic=-10mA, Icbo=5uA, P=100mW, ft=850kHz, Cobo=?pF |
|
| Photo's | : | Picture1, Picture2 |
| GT41-B (AEI) | Type | : | GT41, IF amplification and high speed switching Germanium PNP transistor Low Power |
|
|
Manufacturer | : | Associated Electrical Industries |
| Year | : | End Fifties | |
| Package, Case style | : | None, Light Blue with yellow top and white spot at the side of the transistor | |
| Spec's | : |
Vceo(max)=-?V, Vcbo(max)=-15V, Hfe=30, Ic=-100mA, Icbo=15uA, P=100mW, ft=4MHz, Cobo=15pF |
|
| Photo's | : | Picture1, Picture2, Picture3 |
| GT43 (BTH) | Type | : | GT43, IF amplification and high speed switching Germanium PNP transistor Low Power |
|
|
Manufacturer | : | British Thomson Houston |
| Year | : | End Fifties | |
| Package, Case style | : | None, Blue/green with white top and letter "H" on it and white spot at the side of the transistor | |
| Spec's | : |
Vceo(max)=-?V, Vcbo(max)=-15V, Hfe=100, Ic=-100mA, Icbo=15uA, P=100mW, ft=9MHz, Cobo=15pF |
|
| Photo's | : | Picture1, Picture2, Picture3 |
| GT45 (AEI) | Type | : | GT45, IF amplification and high speed switching Germanium PNP transistor Low Power |
|
|
Manufacturer | : | Associated Electrical Industries |
| Year | : | End Fifties | |
| Package, Case style | : | None, Old Blue with yellow top and Text "RH" on it and white spot at the side of the transistor | |
| Spec's | : |
Vceo(max)=-?V, Vcbo(max)=-25V, Hfe=30, Ic=-100mA, Icbo=15uA, P=100mW, ft=4MHz, Cobo=15pF |
|
| Photo's | : | Picture1, Picture2, Picture3 |
| VR7E (AEI) | Type | : | VR7E, Germanium Power Diode |
|
|
Manufacturer | : | Associated Electrical Industries |
| Year | : | Mid Fifties | |
| Package, Case style | : | None, Old Blue with yellow top and Text "RH" on it and white spot at the side of the transistor | |
| Spec's | : | ||
| Photo's | : | Picture1, Picture2, Picture3 |
