Philips: Vintage Transistors / Diodes Collection
This site contains my collection of vintage transistors and diodes, most of them included with their original package or sleeves. The devices are produced in the late fifties and early sixties except the MOSFET's from Sony they where made in 1975. Enjoy the collectables and click on the picture links for more details. Suggestions regarding these transistors are welcome. I'm always looking for new semiconductor items to complete my collection, so if you would like to sell or exchange something, please contact me, jan@transparentsound.com.
| AAZ12 | Type | : | AAZ12, PNP Germanium Junction Diode |
|
|
Manufacturer | : | Philips |
| Year | : | Mid sixties | |
| Package, Case style | : | Carton box, SO-2 Glass painted black | |
| Spec's | : | Forward Current max = 100mA, Reverse Voltage max =30V(max) | |
| Photo's | : | Picture1, Picture2, Picture3 |
| AC126 | Type | : | AC126, PNP Germanium Transistor, from a Engineer kit out 1960 (Datasheet) |
|
|
Manufacturer | : | Mullard/Philips |
| Year | : | +/-1960 | |
| Package, Case style | : | Carton box, TO-1 | |
| Spec's | : | Vceo=-12V, Vcbo=-32V, Hfe=>65, Ic=-2mA, Icbo=-10uA, Cobo=50pF, P=500mW, ft=1,7MHz(max) | |
| Photo's | : | Picture1, Picture2, Picture3 |
| OA7 | Type | : | OA7, Germanium Gold Bounden Diode (Switching Applications) |
|
|
Manufacturer | : | Philips, (I'm looking for technical data) |
| Year | : | +/-1960 | |
| Package, Case style | : | SO-2, Glass painted black | |
| Spec's | : | VForward Current max = 140mA, Reverse Voltage max = 25V(max), Reverse Current = 150uA(max) | |
| Photo's | : | Picture1 |
| OC13 | Type | : | OC13, PNP Germanium Transistor (Audio Frequency and Pre-Amplifier Applications) (Coming soon) |
|
|
Manufacturer | : | Philips,thanks to Richard den Braber from Holland for his donation of the OC13. see his website: http://NL10609.nl |
| Year | : | End fifties | |
| Package, Case style | : | Carton box, TO-1.. The OC13 is a rebranded OC70, OC71 and introduced as a new device on the Firato show in Holland in October 1956. Thanks Mark Burgess for his historical information, see his website https://sites.google.com/site/transistorhistory/Home/european-semiconductor-manufacturers/philips | |
| Spec's | : | Vceo=-5V, Vcbo=-?V, Hfe=?, Ic=-10mA, Icbo=-?uA, Cobo=?pFmax, P=25mW, ft=?MHz(max) | |
| Photo's | : | Picture1, Picture2 |
| OC43 | Type | : | OC43, PNP Germanium Transistor (Switching Applications) |
|
|
Manufacturer | : | Philips |
| Year | : | +/-1960 | |
| Package, Case style | : | TO-1 | |
| Spec's | : | Vceo=-?V, Vcbo=-15V, Hfe=50-200, Ic=-50mA, Icbo=-?uA, Cobo=?pFmax, P=80mW, ft=12MHz(max) | |
| Photo's | : | Picture1, Picture2 |
| OC44 | Type | : | OC71, PNP Germanium Transistor (Mixer Oscillator |
|
|
Manufacturer | : | Philips |
| Year | : | +/-1960 | |
| Package, Case style | : | TO-1 | |
| Spec's | : | Vceo=-10V, Vcbo=-15V, Hfe=>100, Ic=-1mA, Icbo=-14uA, Cobo=40pFmax, P=40mW, ft=15MHz(max) | |
| Photo's | : | Picture1, Picture2 |
| OC53, OC55, OC55A, OC58 | Type | : | OC53, OC55, OC55A, OC58, PNP Germanium Transistor (Switching Applications) (New) |
|
|
Manufacturer | : | Philips |
| Year | : | early sixties | |
| Package, Case style | : | TO-1 | |
| Spec's | : | Vceo=-?V, Vcbo=-?V, Hfe=?, Ic=-?mA, Icbo=-?uA, Cobo=?pFmax, P=?mW, ft=?MHz(max) | |
| Photo's | : | Picture1, Picture2, Picture3, Picture4, Picture5, Picture6, Picture7, Picture8 |
| OC71 | Type | : | OC71, PNP Germanium Transistor |
|
|
Manufacturer | : | Philips |
| Year | : | +/-1960 | |
| Package, Case style | : | Carton box, TO-1 | |
| Spec's | : | Vceo=-10V, Vcbo=-30V, Hfe=>41, Ic=-1mA, Icbo=-13uA, Cobo=40pFmax, P=125mW, ft=1MHz(max) | |
| Photo's | : | Picture1, Picture2, Picture3, Picture4, Picture5 |
| OC75 | Type | : | OC75, PNP Germanium Transistor (High Gain Amplifiers) |
|
|
Manufacturer | : | Philips |
| Year | : | +/-1960 | |
| Package, Case style | : | TO-1 | |
| Spec's | : | Vceo=-10V, Vcbo=-30V, Hfe=>60-130, Ic=-3mA, Icbo=-14uA, Cobo=40pFmax, P=125mW, ft=1MHz(max) | |
| Photo's | : | Picture1, Picture2 |
| OC140 | Type | : | OC140, NPN Germanium Transistor High Speed, High Current Switching Aplications) |
|
|
Manufacturer | : | Philips |
| Year | : | +/-1960 | |
| Package, Case style | : | Carton box, TO-1 | |
| Spec's | : | Vceo=+?V, Vcbo=+20V, Hfe=50-150, Ic=15mA, Icbo=?uA, Cobo=?pFmax, P=140mW, ft=4,5MHz(max) | |
| Photo's | : | Picture1, Picture2 |
